ASC TS-92V1Tilt sensor

asc_icon_arrow_big

Product Information

Technology:
Sensors of the ASC TS series are based on proven MEMS technology with a capacitive operating principle. The integrated electronic circuitry enables a quasi-differential analog voltage output (±2 V FSO) and flexible power supply voltage from 6 to 40 VDC. The biaxial ASC TS-92V1 tilt sensor features a resolution of <0.005°. In addition, the long-term stability of the scale factor (±300 ppm) and bias (±0.009°) are a basic requirement for the demands of condition and structural health monitoring applications.

Housing:
These tilt sensors feature a lightweight, reliable aluminum housing with protection class IP67 and an integrated cable with configurable length and connectors.

Applications:
Their outstanding resolution and long-term stability make these tilt sensors ideal for the detection of tower swayings, for track alignment and axle alignment, compensation of truck chassis or angular positioning of machine tools.
