Piezoresistive accelerometers

Shock and impact measurements with very high accelerations from ±500 g to ±6,000 g are best achieved with sensors that operate on the basis of the piezoresistive principle. For this purpose, four variable resistors manufactured using MEMS technology are configured as a Wheatstone bridge. This causes a change in the analog voltage output signal proportional to the input acceleration.

Furthermore, this technology also enables the measurement of static or constant accelerations within a frequency response range from DC to 4 kHz – essential in crash test applications such as side and head-on collision tests in the automotive sector.

The sensors are fabricated in lightweight aluminum housings and are available in both uniaxial and triaxial versions. As an additional feature we will be glad to offer you a custom configuration with TEDS and EQX data.

asc_icon_arrow_big

Piezoresistive accelerometers

Our product filter offers a fast and easy way for you to find the right sensor solution for your application.

Interface
Sensor type
Number of sensitive directions
Additional filter options for analog accelerometers:
Sensor technology
Output signal
Frequency range [Hz]
Measurement range [g]
Operating temperature min. [°C]
Operating temperature max. [°C]
Protection class

Would you like a personal consultation or do you need more information?

Contact our team of engineers! We will be glad to help you – at no charge and no obligation.

E-mail: service[at]asc-sensors.de
Phone +49 8441 786547-0

ASC 61C1

Uniaxial, piezoresistive
Measurement range: ±500 to ±2000 g
Housing: Aluminum | 3 gram

ASC 62C1

Uniaxial, piezoresistive
Measurement range: ±500 to ±2000 g
Housing: Aluminum | 3 gram

ASC 66C1

Uniaxial, piezoresistive
Measurement range: ±500 to ±2000 g
Housing: Aluminum | 3 gram

ASC 66C2

Uniaxial, piezoresistive
Measurement range: ±6000 g
Housing: Aluminum | 5 gram

ASC 74C1

Triaxial, piezoresistive
Measurement range: ±500 to ±2000 g
Housing: Aluminum | 16 gram

ASC 75C1

Triaxial, piezoresistive
Measurement range: ±500 to ±2000 g
Housing: Aluminum | 13 gram

ASC 76C1

Triaxial, piezoresistive
Measurement range: ±500 to ±2000 g
Housing: Aluminum | 12 gram
